As we all know, GRC is a kind of fiber-reinforced concrete composite material with alkali resistant glass fiber as reinforcement material and cement mortar as base material. It is also a decorative cement component for building details, so there must be relevant specifications and requirements for the installation of buildings. Otherwise, improper operation will cause personal safety and other unnecessary losses.

那么接下來小編告訴大家GRC構件正確的安裝方法到底是怎樣的?

So what is the correct installation method of GRC components?

一定要提醒大家的是，較大GRC構件的重量比較重，容易掉落下來，所以我們可以通過設置支撐的方法進行臨時加固，方便進行施工。

First of all, we must remind you that the weight of large GRC components is relatively heavy and easy to fall down, so we can set support method for temporary reinforcement to facilitate construction.

一、GRC構件正確的安裝方法:

1、 Correct installation method of GRC components:

1、在待安裝GRC構件的部位按照圖紙彈出定位線(中線或邊線)

1. First, pop out the positioning line (center line or side line) at the position where GRC components are to be installed according to the drawing

2、然后按照施工圖紙說明來安裝尺寸切割GRC構件。在切割GRC構件時，如何把握GRC構件的大小呢?我們要保證其拼接縫寬恰到好處。

2. Then install the dimension cutting GRC components according to the construction drawing. When cutting GRC components, how to grasp the size of GRC components? First of all, we need to ensure that the splicing joint width is just right.

3、在粘貼GRC構件時，可以對網格布進行翻包，也可以直接粘貼。可以使用粘結砂漿，通過薄層滿粘法的方法進行粘貼，可以將砂漿用力的從GRC構件中擠出。其粘接縫應隨粘隨勾，寬度要小于3毫米，保持粘接縫的飽滿和清潔。

3. When pasting GRC components, the grid cloth can be turned over or pasted directly. High quality bonding mortar can be used to paste through thin layer full bonding method, and the mortar can be forced out of GRC members. The gluing joint shall be glued at any time and the width shall be less than 3mm to keep the gluing joint full and clean.

4、進行GRC構件的安裝，先測好GRC構件的大小，先在平地上進行試拼接，如果GRC構件之間的縫隙小于3毫米，則可以使用粘結砂漿進行粘結，注意粘結砂漿的分布均勻。

4. For the installation of GRC components, the size of GRC components shall be measured first, and trial splicing shall be carried out on flat ground first. If the gap between GRC components is less than 3mm, high-quality bonding mortar can be used for bonding, and attention shall be paid to the uniform distribution of bonding mortar.

5、檢查一下拼接完的GRC構件，可以使用砂紙將接縫處的粘結砂漿打磨干凈。在粘結砂漿干燥之后，可以使用GRC構件抗裂專用膠來進行進一步的黏貼。

5. Check the spliced GRC components, and polish the bonding mortar at the joints with sandpaper. After the bonding mortar is dried, GRC component crack resistant adhesive can be used for further bonding.

二、GRC構件安裝的質量標準:

2、 Quality standard for GRC component installation:

1、構件安裝要求橫向平整、豎向垂直、整體上線、花飾組對完整、曲線圓滑流暢，構件表面無污染、缺損。

1. The installation of components requires horizontal flatness, vertical perpendicularity, overall on-line, complete decoration group, smooth and smooth curve, and no pollution and defect on the component surface.

2、構件安裝節點對位準確，防止因埋件錯位導致構件強扭就位，產生安裝應力而日久變形。

2. The installation nodes of the components shall be aligned accurately to prevent the components from being forced to twist in place due to the dislocation of the embedded parts, resulting in the installation stress and long-term deformation.

3、構件連接點必須連接到位，不得遺漏。螺栓連接必須帶緊擰靠。

3. The connection points of components must be connected in place without omission. The bolt connection must be tightened.

4、構件接頭順暢，接縫小于10mm。

4. The joint of components shall be smooth, and the joint shall be less than 10 mm.

5、豎向構件應避免將上部構件層層疊壓在底部構件上，而應將每一截構件單獨懸掛安裝在墻體上。

5. Vertical members shall avoid stacking the upper members on the bottom members, and each member shall be hung and installed on the wall separately.

6、構件安裝完畢，應自上而下將表面的灰塵和污漬清掃干凈，勾縫飽滿、打磨平整。

6. After the installation of components, the dust and stains on the surface shall be cleaned from top to bottom, and the joints shall be full and polished.
